- Bearing System: Ball Bearing
- Cooling System: Oil & Water Cooled
- Horsepower: 310 - 525
- Original GT Series Aerodynamics
- Ball Bearing configuration with Water Cooled CHRA
- Internally Wastegated and Externally Wastegated Turbine Housing Options
| Super Core Reference Data | Compressor | Turbine | ||||||
|---|---|---|---|---|---|---|---|---|
| Supercore PN | CHRA PN | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim |
| 836028-5003S | 836000-0003 | 57mm | 76mm | 56 | 0.60 | 60mm | 55mm | 84 |
| Notes: | Turbine Kit PN | A/R | Inlet | Outlet | Wastegate | Divided | Trim | |
|
Turbine Housing Options |
740902-0009 | 0.63 | T3 | V-Band | Free Float | N | 84 | |
| 740902-0008 | 0.82 | T3 | V-Band | Free Float | N | 84 | ||
| 740902-0015 | 0.63 | T4 | V-Band | Free Float | N | 84 | ||
| 740902-0014 | 0.82 | T4 | V-Band | Free Float | N | 84 | ||
| 740902-0013 | 1.06 | T4 | V-Band | Free Float | N | 84 | ||
| 740902-0036 | 0.61 | V-Band | V-Band | Free Float | N | 84 | ||
| 740902-0035 | 0.83 | V-Band | V-Band | Free Float | N | 84 | ||
| 740902-0034 | 1.01 | V-Band | V-Band | Free Float | N | 84 | ||
| 740902-0024 | 0.61 | V-Band | V-Band | Free Float | Y | 84 | ||
| 740902-0023 | 0.83 | V-Band | V-Band | Free Float | Y | 84 | ||
| 740902-0022 | 1.01 | V-Band | V-Band | Free Float | Y | 84 | ||
| 740902-0030 | 0.61 | T3 | V-Band | Free Float | Y | 84 | ||
| 740902-0029 | 0.83 | T3 | V-Band | Free Float | Y | 84 | ||
| 740902-0028 | 1.01 | T3 | V-Band | Free Float | Y | 84 | ||
| Turbine Assy PN | A/R | Inlet | Outlet | Wastegate | Divided | Trim | ||
| 771300-0006 | 0.63 | T3 | 5 bolt | Wastegated | N | 84 | ||
| 771300-0005 | 0.82 | T3 | 5 bolt | Wastegated | N | 84 | ||
