Garrett=Supercore GT2860RS (Less Turbine Housing)
Garrett=Supercore GT2860RS (Less Turbine Housing)
Garrett=Supercore GT2860RS (Less Turbine Housing)
Garrett=Supercore GT2860RS (Less Turbine Housing)
Garrett=Supercore GT2860RS (Less Turbine Housing)

Drift Racing Industries

Garrett=Supercore GT2860RS (Less Turbine Housing)

  • Sale
  • $1,710.00
  • Bearing System: Ball Bearing
  • Cooling System: Oil & Water Cooled
  • Horsepower: 250 - 360
  • Original GT Series Aerodynamics
  • Ball Bearing configuration with Water Cooled CHRA
  • Internally Wastegated and Externally Wastegated Turbine Housing Options
Super Core Reference Data Compressor Turbine
Supercore PN CHRA PN Inducer Exducer Trim A/R Inducer Exducer Trim
836026-5013S 835998-0007 47mm 60mm 62 0.60 54mm 47mm 76
836026-5014S 835998-0007 47mm 60mm 62 0.60 54mm 47mm 76
Notes: Turbine Kit PN A/R Inlet Outlet Wastegate Divided Trim
Turbine Housing Options XTR013-1186 0.42 T25 5-Bolt Wastegated N 76
827690-0005 0.64 T25 5-Bolt Wastegated N 76
827690-0004 0.86 T25 5-Bolt Wastegated N 76
XTR013-1001 0.64 V-Band 5-Bolt Wastegated N 76
827690-0001 0.57 V-Band V-Band Free Float N 76
827690-0002 0.72 V-Band V-Band Free Float N 76
XTR013-0000 0.61 T3 V-Band Free Float N 76
XTR013-1000 0.64 T3 V-Band Free Float N 76
XTR013-1005 0.73 T3 V-Band Free Float N 76
XTR013-1141 0.61 T25 V-Band Free Float N 76
XTR013-1146 0.71 T25 V-Band Free Float N 76
ATP-HSG-043 0.72 T25 5-Bolt Free Float N 76
