- Bearing Type: Ball Bearing
- Cooling System: Oil & Water Cooled
- Turbine Housing: Internally Wastegated, 0.92a/r
- Base Flange: T04 Dual Entry
- Exhaust Outlet Flange: 3.0" V-Band
- Horsepower: 600-1000hp
Product Notes:
- SPEED RATING; The maximum speed rating for the EFR9180 is 116,000RPM
- The Turbine Outlet V-Band clamp and V-band flange are sold separately
Features of the Borg Warner EFR range of Turbochargers:
- Gamma-Ti turbine wheel (Titanium)
- Integrated Compressor Recirculation Valve (CRV)
- Integrated Boost Control Solenoid Valve (BCSV)
- Dual ceramic ball bearing assembly with metal cage
- Forged milled compressor wheel
- Extended tip compressor wheel. (FMW)
- Compressor housing with speed sensor mounting provisions
- Stainless steel turbine housing
- Water cooled bearing housing
